API Forged Steel Gate Valve

API  Forged Steel Gate Valve

Short Description:

winocean is API Forged Steel Gate Valve manufacturer in china ,...


  • Material : Forged Steel
  • Standards: API
  • Pressure: 125~1500lbs

Product Details

Product Tags

API  Forged Steel Gate Valve


Technical Data:

Standard Nominal Pressure Nominal Diameter Applicable Medium
Z41 150~1500LBS 1/2”~2” Sea Water.Fresh Water

Material of Main Parts:
Item Parts Name Material Code
1 Body Forged Steel A105N/F22
2 Disc Stainless Steel F430/F304
3 Stem Stainless Steel F6A
4 Bonnet Forged Steel A105N/F22
5 Handwheel Carbon Steel WCB

Main Data:
Size L Weight kgs
150 300 600 900~1500 150 300 600 900~1500
1/2” 108 140 165 216 5.00 5.20 5.90 7.20
3/4” 117 152 190 229 6.10 6.30 7.50 11.50
1” 127 165 216 254 8.40 8.60 10.20 15.60
1-1/4” 140 178 229 279 14.30 14.50 16.70 16.20
1-1/2” 165 190 241 305 15.40 15.60 17.40 22.60
2” 178 216 292 368 22.70 22.80 28.70 32.80

Technical Data:

Standard Nominal Pressure Nominal Diameter Applicable Medium
Z11.Z61.HZ11.HZ61 150~1500LBS 1/4”~2” Sea Water.Fresh Water

Material of Main Parts:
Item Parts Name Material Code
1 Body Forged Steel A105N/F22
2 Disc Stainless Steel F430/F304
3 Stem Stainless Steel F6A
4 Bonnet Forged Steel A105N/F22
5 Handwheel Carbon Steel WCB

Main Data:
Size L H Weight kgs
150~600lbs 900~1500 lbs 150~600lbs 900~1500 lbs 150~600lbs 900~1500 lbs
RP FP RP FP RP FP
1/4”     79     166     2.19
3/8” 79 79 92 166 166 166 2.20 2.20 2.17
1/2” 79 92 111 166 169 169 2.20 2.20 2.20
3/4” 92 111 111 169 193 193 2.20 4.30 4.30
1” 111 120 120 193 236 230 4.30 5.90 5.90
1-1/4” 120 120 120 236 246 246 5.90 6.90 6.90
1-1/2” 120 140 140 246 283 283 6.90 11.10 11.10
2” 140 178 178 283 330 330 11.10 15.20 15.20
