JIS F3019 Self Closing Parallel Cock Heads For Sounding Pipe

JIS F3019 Self Closing Parallel Cock Heads For Sounding Pipe

Short Description:

winocean is JIS F3019 Self Closing Parallel Cock Heads For Sounding Pipe manufacturer Brass Sounding Pipe Cap is suitable for sounding device of oil tank and water tank,Source JIS Self Closing Gate Valve Heads For Short Sounding Pipe F3019...


  • Material : Cast Bronze / Brass
  • Standards: JIS

Product Details

Product Tags

JIS F3019 Self Closing Parallel Cock Heads For Sounding Pipe


Technical Data:

Standard Nominal Pressure Nominal Diameter Applicable Medium
JIS F3019 10K 40~80 Sea Water.Fresh Water

Material of Main Parts:
Item Parts Name Material Code
1 Body Bronze/Brass BC6/C3771BD
2 Cover Bronze/Brass BC6/C3771BD
3 Disc Bronze/Brass BC6/C3771BD

Main Data：
Size IMPA CODE d1 d2 L d d5
40A   58 35 180 PF 1-1/2 68
50A   70 50 200 PF 2 70
65A   85 50 200 PF 2-1/2 70
80A   100 50 200 PF 3 70
